Samsung SM-A165F (Galaxy A16) Erase FRP By ISP
تجربة ناجحة
مستوى الحماية على Bootloader (B=11) آخر حماية لتاريخ كتابة هذا الموضوع
بيانات العملية:
الموضوع المرجعي:
Samsung SM-A165F (Galaxy A16) Erase FRP By ISP
Samsung SM-A165F (Galaxy A16) Erase FRP By ISP
تجربة ناجحة
مستوى الحماية على Bootloader (B=11) آخر حماية لتاريخ كتابة هذا الموضوع
بيانات العملية:
كود:
Model Settings:
Interface : UFS
Gear : PWM Gear 1
Connecting to server. Please wait...
Connection to server successful
Pin connector is detected!(eMMC: 1b, UFS: PWM 1-4)
Connecting UFS in ISP gear 1 wait ...Check device ...
Voltages 3.14V;1.19V;1.78V
Please use USB3.0 for better speed.
Connected. Reading information.
Support for security LU: RPMB
Manufacturer name: SAMSUNG
Product name: KM5L9000CM-B424
Serial Number: XS2BEO6MD2
OEM ID: SAMSUNG_OEM_ID
Product Revision Level: 0006
Specification version: 2.20
Page size : 4096 B
Block size : 4096 B
Block count : 31246336
Size : 119.20 GB (122056.00 MB)
Max Number of LU : 8
AttrRefClkFreeq : 26.0 MHz
MaxDataInSize : 4096 bytes
MaxDataOutSize : 4096 bytes
UFS connected succesful.
---------------------------------------------------------------
Physical partition number: 0
Block count : 1024 (0x400)
Size : 4.00 MB
Physical partition number: 1
Block count : 1024 (0x400)
Size : 4.00 MB
Physical partition number: 2
Block count : 31240192 (0x1DCB000)
Size : 119.17 GB (122032.00 MB)
P00: GPT (00000000, 0000C000) 48 KB
P01: md5hdr (0000C000, 003F4000) 4048 KB
P02: efs (00400000, 00800000) 8 MB
P03: sec_efs (00C00000, 00800000) 8 MB
P04: steady (01400000, 00400000) 4 MB
P05: nvram (01800000, 04000000) 64 MB
P06: spmfw (05800000, 00100000) 1024 KB
P07: dpm1 (05900000, 00100000) 1024 KB
P08: scp1 (05A00000, 00200000) 2048 KB
P09: sspm1 (05C00000, 00100000) 1024 KB
P10: mcupm1 (05D00000, 00100000) 1024 KB
P11: gz1 (05E00000, 01000000) 16 MB
P12: lk1 (06E00000, 00600000) 6 MB
P13: uh (07400000, 00200000) 2048 KB
P14: tee1 (07600000, 00200000) 2048 KB
P15: dtbo (07800000, 00800000) 8 MB
P16: vbmeta (08000000, 00010000) 64 KB
P17: tzar (08010000, 00400000) 4 MB
P18: btd (08410000, 00BF0000) 11.94 MB
P19: protect1 (09000000, 00800000) 8 MB
P20: protect2 (09800000, 00800000) 8 MB
P21: seccfg (0A000000, 00800000) 8 MB
P22: bota (0A800000, 03400000) 52 MB
P23: boot_para (0DC00000, 00100000) 1024 KB
P24: dram_para (0DD00000, 01900000) 25 MB
P25: para (0F600000, 00080000) 512 KB
P26: misc (0F680000, 00080000) 512 KB
P27: frp (0F700000, 00100000) 1024 KB
P28: nvcfg (0F800000, 02000000) 32 MB
P29: nvdata (11800000, 04000000) 64 MB
P30: metadata (15800000, 04000000) 64 MB
P31: keyrefuge (19800000, 01000000) 16 MB
P32: keydata (1A800000, 01000000) 16 MB
P33: persistent (1B800000, 00080000) 512 KB
P34: proinfo (1B880000, 00300000) 3072 KB
P35: md1img (1BB80000, 0C800000) 200 MB
P36: pi_img (28380000, 00100000) 1024 KB
P37: param (28480000, 00800000) 8 MB
P38: up_param (28C80000, 00800000) 8 MB
P39: boot (29480000, 04000000) 64 MB
P40: recovery (2D480000, 05000000) 80 MB
P41: vendor_boot (32480000, 04000000) 64 MB
P42: init_boot (36480000, 00800000) 8 MB
P43: bspdb (36C80000, 01000000) 16 MB
P44: vbmeta_system (37C80000, 00010000) 64 KB
P45: vbmeta_vendor (37C90000, 00010000) 64 KB
P46: expdb (37CA0000, 08000000) 128 MB
P47: connsys_bt (3FCA0000, 00800000) 8 MB
P48: connsys_wifi (404A0000, 00800000) 8 MB
P49: connsys_gnss (40CA0000, 00800000) 8 MB
P50: efuse (414A0000, 00080000) 512 KB
P51: reserved (41520000, 002E0000) 2944 KB
P52: sec1 (41800000, 00800000) 8 MB
P53: super (42000000, 2EE000000) 11.72 GB
P54: prism (330000000, 3B600000) 950 MB
P55: optics (36B600000, 01800000) 24 MB
P56: cache (36CE00000, 15E00000) 350 MB
P57: omr (382C00000, 03200000) 50 MB
P58: userdata (385E00000, 1A44E00000) 105.1 GB
Backuping efs partition from start 00000400, size 00000800 ...
Opening C:/Program Files (x86)/Medusa Pro Software/Backups/SAMSUNG_KM5L9000CM-B424_efs_0x400_0x800_27_10_2026_12_08_04.bin file...
Reading. Please wait...Done.
Elapsed time 00:00:13
SW: 2.2.5.8; FW: 1.00.
Backuping nvdata partition from start 00011800, size 00004000 ...
Opening C:/Program Files (x86)/Medusa Pro Software/Backups/SAMSUNG_KM5L9000CM-B424_nvdata_0x11800_0x4000_27_10_2026_12_08_04.bin file...
Reading. Please wait...Done.
Elapsed time 00:01:49
SW: 2.2.5.8; FW: 1.00.
---------------------------------------------------------------
Searching Android build info...
Build ID : BP4A.251205.006
Display Build ID : BP4A.251205.006.A165FXXSBDZH6
Release ID : 16
Architecture ABI : arm64-v8a
Architecture ABI List : arm64-v8a,armeabi-v7a,armeabi
Build Description : a16nsxx-user 16 BP4A.251205.006 A165FXXSBDZH6 release-keys
---------------------------------------------------------------
Writing /system/build.prop file
C:/Program Files (x86)/Medusa Pro Software/Logs/BUILD_PROP_SAMSUNG_KM5L9000CM-B424_27_10_2026_12_10_09.txt
---------------------------------------------------------------
RPMB: Counter of the successful data write requests = 3335.
LUN 0 info:
Found WP Area at Lun 0 with WPT - NV-type: WPF bit is persistent through power cycle and hardware reset.WPFlag value may only be changed writing to Secure Write ProtectConfiguration Block. and WPF - Secure Write Protection is disabled. start: 0x0 and size: 0x0(Lun: 0; WPT: 0; WPF: 0; start: 0x0; size: 0x0)
LUN 1 info:
Found WP Area at Lun 1 with WPT - NV-type: WPF bit is persistent through power cycle and hardware reset.WPFlag value may only be changed writing to Secure Write ProtectConfiguration Block. and WPF - Secure Write Protection is disabled. start: 0x0 and size: 0x0(Lun: 1; WPT: 0; WPF: 0; start: 0x0; size: 0x0)
LUN 2 info:
Found WP Area at Lun 2 with WPT - NV-type: WPF bit is persistent through power cycle and hardware reset.WPFlag value may only be changed writing to Secure Write ProtectConfiguration Block. and WPF - Secure Write Protection is disabled. start: 0x0 and size: 0x0(Lun: 2; WPT: 0; WPF: 0; start: 0x0; size: 0x0)
Partition table has been found on device.
Don't forget to reconnect the device after writing to see changes.
Writting partitions. Please wait...
Physical partition number: 2
Writing partition misc from E:/ISP JTAG/Repair by UFS/SAMSUNG/SM-A165F SM-A165M/misc_512k_zero.bin file... Done.
Physical partition number: 2
Writing partition frp from E:/ISP JTAG/Repair by UFS/SAMSUNG/SM-A165F SM-A165M/frp_1MB_zero.bin file... Done.
Physical partition number: 2
Writing partition persistent from E:/ISP JTAG/Repair by UFS/SAMSUNG/SM-A165F SM-A165M/persistent_512k_zero.bin file... Done.
Writing is finished.
