سحـــــDUMPــــب tablette KLIVER klipad D71 على EFT

[pera]

- سحب DUMP لتاب KLIVER klipad D71 على EFT​

1. انفو :​

Waiting For Device Connection......OK
Opening USB Connection.........OK
- Device ID: \\?\usb#vid_1f3a&pid_efe8#6&b6e276f&0&2#{0e57c50f-0ccc-4ad2-a895-93c5ed119860}
- Device MODE: FEL
FEL Information:
- Version: 0x00166700
- CPU: A33|Quad-Core ARM Cortex-A7 @ 1.2GHz
- Opening Loader File: OK
Fel2Fes Transition:
- Command:.. FesTransCmd executed successfully
- Status: OK
Waiting For FES Device......OK
Opening USB Connection.........OK
- Device ID: \\?\usb#vid_1f3a&pid_efe8#6&b6e276f&0&2#{0e57c50f-0ccc-4ad2-a895-93c5ed119860}
- Device MODE: FES
Erasing Flag...OK
Verifying Status...OK
Querying Storage...- Storge Type: nand
Enabling Flashing Mode...OK
- Flash Size: 14696448
Partition Table..OK
Server...OK
- uboot : 0 - 32768
- bootloader : 32768 - 65536
- env : 98304 - 32768
- boot : 131072 - 32768
- system : 163840 - 2097152
- data : 2260992 - 2097152
- misc : 4358144 - 32768
- recovery : 4390912 - 65536
- cache : 4456448 - 1048576
- metadata : 5505024 - 32768
- private : 5537792 - 32768
Disabling Flashing Mode...OK
=======================
Operation Completed

2. انفو السحب :​

Waiting For Device Connection......OK
Opening USB Connection.........OK
- Device ID: \\?\usb#vid_1f3a&pid_efe8#6&b6e276f&0&2#{0e57c50f-0ccc-4ad2-a895-93c5ed119860}
- Device MODE: FEL
FEL Information:
- Version: 0x00166700
- CPU: A33|Quad-Core ARM Cortex-A7 @ 1.2GHz
- Opening Loader File: OK
Fel2Fes Transition:
- Command:.. FesTransCmd executed successfully
- Status: OK
Waiting For FES Device......OK
Opening USB Connection.........OK
- Device ID: \\?\usb#vid_1f3a&pid_efe8#6&b6e276f&0&2#{0e57c50f-0ccc-4ad2-a895-93c5ed119860}
- Device MODE: FES
Erasing Flag...OK
Verifying Status...OK
Querying Storage...- Storge Type: nand
Enabling Flashing Mode...OK
- Flash Size: 14696448
Partition Table..OK
Server...OK
- uboot : 0 - 32768
- bootloader : 32768 - 65536
- env : 98304 - 32768
- boot : 131072 - 32768
- system : 163840 - 2097152
- data : 2260992 - 2097152
- misc : 4358144 - 32768
- recovery : 4390912 - 65536
- cache : 4456448 - 1048576
- metadata : 5505024 - 32768
- private : 5537792 - 32768
Read Dump:
- Reading uboot : OK
- Reading bootloader : OK
- Reading env : OK
- Reading boot : OK
- Reading system : OK
- Reading misc : OK
- Reading recovery : OK
- Reading metadata : OK
- Reading private : OK
Disabling Flashing Mode...OK
=======================
Operation Completed
